The typical computer desk is plagued by a tangled mess of cables: a laptop power adapter, an external docking station, a phone charging stand, an SD card reader, and miscellaneous USB cables cluttering the workspace. You can explore Anker 675 official store options here or check Amazon Prime availability here.
The Anker 675 USB-C Docking Station (12-in-1, Monitor Stand) is designed to eliminate this chaos with an ingenious 2-in-1 concept: elevating your display to an ergonomically correct eye level while housing a full-featured 100W USB-C hub directly inside an aircraft-grade aluminum monitor stand.
Technical Specifications & Laboratory Benchmark Summary
| Metric / Specification | Anker 675 Measurement | Standard USB-C Docking Station | Lab Score |
|---|---|---|---|
| Total Ports | 12 Hub Ports + Qi Charging | 7 to 9 Ports | 9.6 / 10 |
| Max Upstream Laptop PD | 100W Max Fast Charging | 65W - 85W | 9.8 / 10 |
| Display Output | 1x HDMI 2.0 (4K @ 60Hz) | 2x DisplayPort / HDMI | 8.2 / 10 |
| Data Transfer Speeds | 10Gbps USB-C 3.2 Gen 2 / USB-A | 5Gbps USB 3.0 | 9.5 / 10 |
| Wireless Charging Pad | 10W Qi Wireless Fast Charge | None | 9.8 / 10 |
| SD / MicroSD Card Slots | UHS-I (104 MB/s Concurrent) | Often Single or Missing | 9.2 / 10 |
| Top Plate Load Capacity | 22.0 lbs (10.0 kg) Aluminum | Plastic Riser (10 - 15 lbs) | 9.4 / 10 |
| Ethernet Controller | Gigabit Ethernet (1000 Mbps RJ45) | Gigabit RJ45 | 9.5 / 10 |
1. 12-Port Connectivity & Side I/O Access
Instead of forcing you to fumble behind your monitor or stretch cables across the desk, Anker split the port layout into two distinct logical zones:
- Left-Side Rapid Access Ports:
- 1x USB-C (10Gbps, 45W PD fast charging for tablets or phones).
- 1x USB-A (10Gbps, 7.5W).
- SD and MicroSD card slots (both can be read simultaneously).
- 3.5mm combined audio / microphone jack.
- Underside Permanent Routing Cavity:
- 1x Host USB-C upstream port (delivering up to 100W to your laptop).
- 1x HDMI 2.0 port (4K @ 60Hz).
- 2x USB-A 2.0 ports (ideal for keyboard/mouse 2.4GHz dongles).
- 1x Gigabit Ethernet port (RJ45).
- Built-in silicone cable clips that wind excess cord slack neatly underneath the stand.
2. Power Delivery & Thermal Stress Testing
We subjected the Anker 675 to our 8-hour thermal chamber stress test while charging a 16-inch Apple M3 Max MacBook Pro under 100% CPU/GPU render load, simultaneously transferring 200 GB of files across the 10Gbps USB-C port, and charging an iPhone 15 Pro on the wireless pad:
| Component / Test Node | Measured Electrical Delivery | Operating Temperature | Stability Status |
|---|---|---|---|
| Laptop Host Upstream | 96.4W Continuous (100W Spec) | 36.9°C (98.4°F) | 100% Stable (No Throttling) |
| Top Qi Wireless Coil | 9.8W to Qi Target Receiver | 31.2°C (88.1°F) | Safe Thermal Cutoff Active |
| Aluminum Top Surface | Passive Heat Sink Dissipation | 23.4°C (74.2°F) | Cool to Touch |
| Gigabit RJ45 Controller | 942 Mbps Sustained Stream | 34.1°C (93.4°F) | Zero Packet Loss |
The aluminum chassis acts as an oversized passive heatsink, drawing heat away from the internal silicon controller chips and keeping temperatures well within safe thresholds.
3. Structural Load Capacity & Monitor Ergonomics
The stand measures 21.3 inches wide, 8.7 inches deep, and 3.5 inches tall. Its top surface is formed from an aircraft-grade aluminum alloy plate finished with a sandblasted matte texture:
- Load Deflection Test: We placed a 34-inch curved ultrawide monitor weighing 18.4 lbs on the center of the stand. The measured central sag was less than 0.25 mm, exhibiting zero creaking or flex.
- Desk Storage Reclaim: Because the stand is elevated by 3.5 inches, you can slide a full-sized mechanical keyboard (up to 19 inches wide) and mouse underneath the stand when not in use, instantly reclaiming 40% of your open desk space for writing or sketching.
- Wireless Charging Zone: The right corner features an etched circle with an integrated Qi wireless induction coil. It delivers up to 10W for Samsung devices and 7.5W for iPhones, with smart foreign object detection that shuts off charging if metal keys are placed on the coil.
4. Anker 675 vs Standalone Dock + Desk Shelf Setup
| Setup Component | Anker 675 (All-in-One) | Grovemade Shelf + CalDigit TS4 Dock |
|---|---|---|
| Combined Cost | $249 | $650 - $750 |
| Desk Footprint | Clean single-unit footprint | Requires dock brick + riser shelf + power strips |
| Power Delivery | 100W USB-C PD | 98W Thunderbolt 4 |
| Display Outputs | Single 4K @ 60Hz HDMI | Dual 4K/60Hz or Single 8K (Thunderbolt 4) |
| Wireless Charging | Integrated on top surface | Requires separate Qi pad |
Final Verdict: Is the Anker 675 Worth It?
If you use a single external 4K or ultrawide display and want to eliminate external docks, power strips, and loose cables from your desk in one fell swoop, the Anker 675 is the smartest, cleanest multi-purpose workspace accessory on the market.
- Anker Direct: Order Anker 675 at Anker Official
- Amazon Prime Direct: View Anker 675 on Amazon
✓ Laboratory Benchmarks: What We Liked
- 12-in-1 connectivity consolidates power, video, high-speed data, and audio into one hub
- Solid aircraft-grade aluminum top plate effortlessly supports monitors up to 34 inches (22 lbs)
- Integrated 10W wireless charging pad keeps phones and earbuds topped up without extra cords
- 100W max upstream Power Delivery charges 16-inch MacBook Pros and high-spec Windows laptops
- Internal cable-wrapping cavity conceals excess cords directly beneath the stand
✕ What Could Be Improved
- Limited to a single external 4K 60Hz display output via HDMI (no native dual display support)
- Fixed elevation height of 3.5 inches cannot be adjusted up or down
- Heavy external 180W power supply brick requires under-desk mounting
